SAS 29PIN to SATA 7PIN+BIG 4PIN Cable 45cm

Product Categories

Chongqing ShuangYi Precision Electronic Co., LTD

Contact Now

SAS 29PIN to SATA 7PIN+BIG 4PIN Cable 45cm

Name: SAS 29PIN to SATA 7PINBIG 4PIN Cable 45cm
Brand: SHUANG YI
Price: 1 USD

Quality SAS 29PIN to SATA 7PIN+BIG 4PIN Cable 45cm for sale

MOQ : Negotiation

Price : Negotiation

Brand Name : SHUANG YI

Model Number : SATA Cable

Certification : ISO9001/SGS/UL/ROHS/Reach

Place of Origin : Guangdong, China (Mainland)

Supply Ability : 100000 per month

Delivery Time : 7~10 Work days

Packaging Details : 1.Custom polybag packing 2.Custom paper box packing 3.According to client's request

Use : Computer

Length : 50cm

Side 1 : 4*7PIN

Side 2 : 4*29PIN

Side 3 : 20 Hole housing

PVC : Completed

Contact Now

SAS 29PIN to SATA 7PIN+BIG 4PIN Cable 45cm

Product Features:

Guaranteed performance at 3.0 Gb/s

Micro GigaCN (SFF-8470) connector in thumbscrew type connector housing for durability

Spectra-strip technology 26 AWG conductors SATA Cabling

Molded SATA plug

Straight SAS to SATA connection

Components are UL listed

Available in lengths ranging fro 1m to 5m

RoHS compliant

Specifications:

1.Housing: PA 66
2.Terminal: Phosphor bronze
3.Cable: Signal wire: 26AWG, solid tinned copper
4.Screen: aluminum foil

eSATA 7 Pin to 7Pin cable, Sata cable.

Description:

eSATA 7 Pin to 7Pin cable

External direct attached storage for notebook, desktop, customer electronics and entry server.

For connecting E- SATA device to an E-SATA host card, both ends are same.

Supports 3GB/second SATA II specification as well as SATA.

Material:

Housing: PA 66

Terminal: Phosphor bronze

Cable: Signal wire: 26AWG, solid tinned copper, Nonconductor: foam Polyolefin;

Earthling conductor: 28AWG, solid copper; Screen: aluminum foil; Jacket: 0.020 PVC, red color. Cover: ABS, black color

Electrical:

Hi-Pot Test: DC 300V

Insulation Resistance: 10M Ohms ( Min)

Contact Resistance (Initial): 1 Ohms (Max)

Withstanding Voltage:500 V AC 1Minute

Test:100% open short and Miss Wire Test.

Mechanic:

Insertion Force: 45N Max.

Withstanding Force: 15 N Min

Operating Temperature: - 25 to 85 °C

Transfer rate: Supports 3.0Gbps

Packing: PE bag, Blister packing, or according to customer's request.

Product Tags:

sata power cable

serial ata data cable

SAS 29PIN to SATA 7PIN+BIG 4PIN Cable 45cm Images
